B62 C83600 Floating Ball Valves

Description

Technical Data Sheet

B62 C83600 Bronze Floating Ball Valve — 2-Piece Split Body, Bolted

Valve Type: Floating Ball Valve, Full Bore, 2-Piece Split Body, Bolted Construction
Body Material: ASTM B62 (UNS C83600) – Leaded Tin Bronze (85-5-5-5)
Model Example: FBV-50A-5K-FL-B62-2P-BOLTED
Nominal Size: 15A (DN15) – 100A (DN100); ½” – 4″
Pressure Class Options: JIS 5K / 10K, ASME Class 150 / 300, PN16/PN25, 150 WOG – 600 WOG
Operation: Manual Lever Handle (standard); gear operator or automated actuator upon request

1. Design Standards & General Specifications

Item Standard / Specification
Design & Manufacturing API 608 (Metal Ball Valves), ASME B16.34, MSS SP-110, BS 5351
Body Style Two-Piece Split Body, Bolted
Face-to-Face Dimensions ASME B16.10, JIS B2002, EN 558, Manufacturer’s Standard
Flanged End Dimensions ASME B16.5, JIS B2220, EN 1092-1
Threaded End Dimensions ASME B1.20.1 (NPT), ISO 7-1 (BSPT/Rp)
Inspection & Testing API 598, JIS B2003, MSS SP-110
Fire-Safe Design (Optional) API 607 / ISO 10497
Pressure-Temperature Rating ASME B16.34 (Bronze Material Group)
Applicable Media Seawater, Fresh Water, Steam, Oil, Gas, and mild chemical services
Temperature Range −29 °C to +260 °C (dependent on seat material, see Section 2)
Marking MSS SP-25
2. Pressure-Temperature Ratings

B62 C83600 bronze floating ball valves are available in a range of pressure classes and configurations depending on connection type and seat material. The table below summarizes common configurations:

Pressure Rating Connection Type Seat Material Temperature Range
JIS 5K JIS B2220 5K Flanged (FF) RPTFE −29 °C to +120 °C
150 WOG / 150 SWP NPT Threaded PTFE −20 °C to +220 °C
Class 1500 (ASME B16.34) NPT Threaded (ASME B1.20.1) PEEK −40 °C to +260 °C
PN25 (25 bar) NPT/BSP Threaded PTFE Ambient to +120 °C
Pressure/temperature ratings for B62 C83600 bronze shall comply with the bronze material group limits per ASME B16.34. Standard ratings include 150 WOG / 150 SWP for general service, 200 WOG / 200 SWP for medium pressure, and 600 WOG for higher-pressure threaded applications. The maximum working pressure shall be derated at elevated temperatures in accordance with the applicable standard. For JIS-rated valves, test pressures conform to JIS B2003.

Mechanical Properties – ASTM B62 C83600 Sand Cast Alloy:

Tensile Strength: ≥ 205 MPa (30 ksi)
Yield Strength (0.5% elongation under load): ≥ 95 MPa (14 ksi)
Elongation in 2 in. (50 mm): ≥ 20%
3. Materials of Construction

The two-piece split body design consists of a main body and a tailpiece (end connector), joined by a bolted connection with a body gasket. All components are selected for compatibility with bronze body material and service conditions.

Component Material Material Standard / Grade
Body (Main Body) Cast Tin Bronze (85-5-5-5) ASTM B62 (UNS C83600)
Tailpiece (End Connector) Cast Tin Bronze ASTM B62 (UNS C83600)
Body Bolts Stainless Steel ASTM A193 B8 / A194 8
Ball Stainless Steel 316 / Monel® K500 ASTM A351 CF8M / UNS N05500
Stem Stainless Steel 316 / Monel® K500 ASTM A276 Type 316 / UNS N05500
Seat / Seal Ring PTFE / RPTFE (Reinforced PTFE) / PEEK Virgin PTFE / 15% Glass-Filled PTFE / PEEK
Stem Packing PTFE / Reinforced PTFE / Graphite-Impregnated PTFE —
Body Gasket (Split Body Seal) PTFE / Reinforced Graphite / Non-Asbestos Fiber —
Thrust Washer / Bearing PTFE + Stainless Steel / PEEK —
Handle / Lever Carbon Steel (Zinc Plated or Epoxy Coated) / Stainless Steel —
Handle Sleeve (Grip) Vinyl / PVC —
Material Notes:

Ball and stem in 316 Stainless Steel (CF8M) is the standard trim for general industrial service, providing excellent corrosion resistance in water, steam, and oil applications.
For enhanced seawater corrosion resistance and high-pressure service, Monel® K500 ball and stem is available as an optional trim material, suitable for marine, offshore, and mildly sour environments.
Seat material options: PTFE for general applications up to ~200 °C; RPTFE (glass-filled) for improved wear and dimensional stability; PEEK for high-temperature and high-pressure service up to 260 °C.
Actuator mounting flanges to ISO 5211 are available upon request.
External surface finish: sandblasted and degreased as standard.
4. Dimensions & Weights

Flanged End (JIS 5K / 10K):

DN NPS Face-to-Face L (mm) Approx. Height H (mm) Approx. Weight (kg) Operation
15 ½ 108 (JIS 5K) 80 2.0 Lever
20 ¾ 117 82 2.5 Lever
25 1 127 102 3.5 Lever
32 1¼ 140 131 5.0 Lever
40 1½ 165 131 7.0 Lever
50 2 178 153 10 Lever
65 2½ 190 225 15 Lever
80 3 203 277 20 Lever / Gear
100 4 229 277 28 Gear
Threaded End (NPT, Class 150 / 300 / 600 WOG):

DN NPS Face-to-Face L (mm) Approx. Height H (mm) Approx. Weight (kg) Handle Diameter D (mm)
15 ½ 54 47 0.5 80
20 ¾ 61 54 0.8 82
25 1 72.5 58 1.2 102
32 1¼ 80.5 66 1.8 131
40 1½ 93 72 2.5 131
50 2 112 89 3.5 153
*Flanged-end dimensions based on JIS B2220 5K FF standard; NPT threaded dimensions per manufacturer’s standard for marine bronze ball valves. Final dimensions should be confirmed with the manufacturer’s certified drawing.*

5. Testing & Inspection

Test Item Test Medium Test Pressure Standard
Shell Hydrostatic Test Water 1.5 × Rated CWP (e.g., 750 psi for 500 psi rated; 2.1 MPa for JIS 5K / 1.4 MPa rated) API 598 / JIS B2003
High-Pressure Seat Test Water 1.1 × Rated CWP (e.g., 550 psi for 500 psi rated; 0.55 MPa for JIS 5K) API 598 / JIS B2003
Low-Pressure Seat Test Air 0.6 MPa (80–90 psi) API 598 / MSS SP-110
Visual & Dimensional — — MSS SP-25, MSS SP-55
Quality Control:

100% chemical analysis and mechanical property testing on raw materials of each heat number.
100% Dye Penetrant Testing (DPT) on castings; Magnetic Particle Testing (MT) or Ultrasonic Testing (UT) performed on selected components; Radiographic Testing (RT) available upon request.
100% hydraulic shell test, seat test, and low-pressure air seat test on every valve.
Documentation:

Material traceability and test reports per EN 10204 3.1 or 3.2.
Certificates of conformity, NDE reports, and fire-safe certification (as applicable).
6. Design Features

Feature Description Benefit
Two-Piece Split Body, Bolted Valve body is split into two main pieces (main body and tailpiece) joined by high-strength bolting and a body gasket. Robust pressure containment; easy disassembly for maintenance; fewer leakage paths than three-piece designs.
Floating Ball Design The ball is not fixed but floats between the seats, pressed against the downstream seat by line pressure. Provides reliable bi-directional sealing; simple construction with fewer parts.
Full Bore (Full Port) The ball bore diameter matches the nominal pipe size. Minimal pressure drop, maximum flow capacity; suitable for pigging applications.
Anti-Blowout Stem Stem is bottom-loaded with an integral shoulder that engages a mating recess in the body. Prevents stem ejection under line pressure, even if the packing gland is removed.
Anti-Static Design Conductive spring or ball between stem and ball ensures electrical continuity. Prevents static electricity buildup; essential for flammable/explosive media service.
Fire-Safe Construction Secondary metal seat backup behind the primary soft seat; graphite stem packing. Maintains sealing integrity during and after fire exposure (API 607 certified).
Bolted Body Gasket Access The split body joint is sealed by a replaceable gasket, accessible by removing the body bolts. Simplifies seat and ball maintenance; reduces downtime.
Lever Handle with Locking Device Standard lever handle with locking provision in open and closed positions. Prevents unauthorized or accidental operation; clear visual open/closed indication.
Corrosion-Resistant Bronze Body ASTM B62 C83600 leaded tin bronze (85-5-5-5) provides excellent resistance to seawater, steam, and mild chemicals. Long service life in marine, industrial, and general-purpose fluid handling applications.
Smooth Surface Finish Sandblasted and degreased external surface as standard. Clean finish free from contaminants, suitable for industrial and marine environments.
7. Ordering Information

When ordering, please specify the following:

Valve Type: Floating Ball Valve, 2-Piece Split Body, Bolted
Nominal Size (DN or NPS): e.g., 50A (DN50) / 2″
Pressure Rating: JIS 5K / 10K, ASME Class 150 / 300, PN16 / PN25, or WOG Rating (150 / 200 / 600 WOG)
Body Material: ASTM B62 (UNS C83600) Cast Bronze
Ball & Stem Material: 316 Stainless Steel (standard) or Monel K500 (marine/sour service)
Seat / Seal Material: PTFE / RPTFE / PEEK
Connection Type: Flanged (JIS B2220 5K/10K FF, ASME B16.5 RF, EN 1092-1 PN16), Threaded (NPT, BSPT, BSP), or Socket Weld
Bore Type: Full Bore (standard) or Reduced Bore
Operation: Manual Lever Handle, Gear Operator, or Actuator (Pneumatic / Electric)
Fire-Safe Certification: API 607 — Required (Yes/No)
Special Requirements: Anti-static design, locking device, extended stem, oxygen cleaning, NACE MR0175 compliance
Documentation Level: EN 10204 3.1 / 3.2 Certificates, NDE Reports, PMI Reports
8. Model Designation Guide

The following naming convention can be used to specify the valve configuration, including the two-piece bolted body:

Segment Code Options Description
Valve Type FBV-2P Floating Ball Valve, 2-Piece Body
Size 15A, 20A, 25A, 40A, 50A, … / ½″, ¾″, 1″, 1½″, 2″, … Nominal size (DN or NPS)
Pressure Class 5K, 10K, 150, 300, PN16, PN25, 600WOG Pressure rating
Connection FL, NPT, BSPT, SW Flanged / Threaded / Socket Weld
Body Material B62 ASTM B62 C83600 Bronze
Ball/Stem Material 316, MK500 316 SS or Monel K500
Options FS (Fire-Safe), AS (Anti-Static), LO (Locking Device), ES (Extended Stem) Optional features
Example: FBV-2P-50A-5K-FL-B62-316-FS
→ Floating Ball Valve, 2-Piece Split Body, 50A, JIS 5K Flanged, B62 Bronze Body, 316SS Trim, Fire-Safe.

9. Spare Parts & Repair Kits

Part Description Material Remarks
Seat Ring Set (2 pcs) PTFE / RPTFE / PEEK Select per service temperature and media
Stem Packing Set PTFE / Graphite-filled PTFE Includes packing rings and gland O-ring
Body Gasket / Seal PTFE / Non-Asbestos For sealing the two-piece split body joint
Thrust Washer PTFE + SS / PEEK Stem bearing
Ball + Stem Assembly 316 SS / Monel K500 Complete trim replacement kit
Handle Assembly Carbon Steel / SS With locking device and sleeve
Body Bolts & Nuts (Set) Stainless Steel Replacement fasteners for the split body
Repair kits for all common sizes (½″ through 4″) are available and can be supplied with the valve or ordered separately. All parts are designed specifically for the 2-piece bolted body configuration.

Note: All dimensions, weights, and pressure ratings are provided for reference and must be confirmed with the manufacturer’s certified drawings and documentation. For critical or high-pressure applications, full material traceability and additional NDE testing (RT, UT, PMI) are recommended. Consult the manufacturer for specific application engineering support.
